Kinematics for a great progressionWith L'Update of our well -known F.O.L.D., your jam is ready to pieces the trails even more. We have maintained the welcome sensitivity of the F.O.L.D. But changed the positioning of our kinematic within the frame for a st
With L’Update of our well -known F.O.L.D., your jam is ready to pieces the trails even more. We have maintained the welcome sensitivity of the F.O.L.D. But changed the positioning of our kinematic within the frame for a strong resistance to the race fund. The characteristics are completely progressive, which translates into a chassis that offers a lot of stability on accidental soils. This allows you to manage any path while the frame still offers comfort for long laps. In addition, Jam’s lower standover gives you more space to play on the paths.
Chassis7005 Hydroformed Aluminium, 3D Forging, 150 mm F.O.L.D. Gen2 Kinematics, 148×12 mm Thru Axle, Internal Cable Routing, Post Mount 180 mm
ForkRock Shox Revelation RC 29 Boost, Debonair, 110×15 mm, 46 mm rake
Fork excursion150 mm
Shock absorberRockshox Deluxe Select, 210/55 mm, Hardware: 25.0 x 8mm, Custom Tune
ChangeSram SX EAGLE, 12-Speed
Rear deraillerSRAM NX EAGLE, 12-Speed
CassetteSRAM PG-1210 EAGLE, 12-Speed
ChainSram SX EAGLE, 12-Speed
CharSRAM NX EAGLE
Transmission systemFront: 32, Rear: 11-50
Central movementBSA
HandlebarAluminium, 800 mm, Rise: 30 mm, Backsweep: 9th
KnobFocus Locker SL
Handlebar attackFocus C.I.S. 50 mm, 0 , 35 mm, Aluminium
Steering seriesACROS ZS56/ZS56 (ICR), Focus C.I.S. Integrated
SaddleSelle Royal Groove Srx
BraPost Modern Dropper Post PM-171, 31.6 mm
Front / rear brakesSRAM DB8, Front: 4-Piston / Rear: 2-Piston / SRAM DB8, Front: 4-Piston / Rear: 2-Piston
Front brake disc203 mm
Rear brake disc180 mm
Rear circleRhodes Tryp30, 30-622
Front hubShimano TC500, 15×110 mm
Rear hubShimano Deore, 12×148 mm
RaysNiro, black
Front / rear tiresMAXXIS MILION DHF, EXO, 63-622 / MAXXIS MILION DHF, EXO, 63-622
Paso (kg)16 kg ()
Weight of the permitted system110 kg
* Subject to technical changes without notice. Excluding errors and omissions.** Weight in the Size M, standard and without pedals specifications.
| S | M | L | XL | ||
|---|---|---|---|---|---|
| Size in mm | 390 | 420 | 450 | 470 | |
| Handlebar width | 780 | 780 | 780 | 780 | |
| Handbridge attachment length | 50 | 50 | 50 | 50 | |
| Length patella | 170 | 170 | 170 | 170 | |
| Reggisella length | 390 | 440 | 440 | 490 | |
| TO | Seat tube length | 390 | 420 | 450 | 470 |
| B | Top tube length | 570 | 603 | 637 | 672 |
| C | Steering angle () | 65.5 | 65.5 | 65.5 | 65.5 |
| D | Seat Tube corner () | 76.5 | 76.5 | 76.5 | 76.5 |
| AND | Length of the horizontal sheath | 435 | 435 | 435 | 435 |
| F | Bottom Bracket Drop | 24 | 24 | 24 | 24 |
| G | Head Tube length | 90 | 100 | 120 | 140 |
| H | Fork length | 561 | 561 | 561 | 561 |
| THE | Offset fork | 44 | 44 | 44 | 44 |
| J | Steps | 1166 | 1200 | 1238 | 1277 |
| K | Stack | 603 | 612 | 630 | 648 |
| L | Reach | 425 | 455 | 485 | 515 |
| M | Standover measurement | 766 | 766 | 766 | 766 |
